Horizontal Foam Cutting Machine

Horizontal Foam Cutting Machine

Rigid Polyurethane Foam Machine

Type  Foam Machine
Rated Power  9.74kw
Dimensions  W1650mm*L2000mm
Voltage  3phase 380v 50hz
No-Load Rotational Speed  0-15m/min
Certification  CE
Application  Foam Industry, Sponge Industry, Furniture Industry
Supply Ability  40 Sets Per Month
Contact us
Products Description

Products Name:

Rigid Polyurethane Foam Machine

Features:

Specializing for cutting phenolic foam blocks and rigid foam blocks.

The cut off foam slice is need of being taken away from working table after each cutting.

The cutting angle of the knife guidance can be adjusted from 0º to 5º.

Specifications

Type

A

B

Cutting Foam Size:

W1650mm*L2000mm

W2150mm*L3000mm

Cutting Foam Height:

H1200mm

H1200mm

Cutting Thickness:

5mm Up

5mm Up

Cutting Speed:

0~15m/min(Adjustable)

0~15m/min(Adjustable)

Blade Length:

L6900mm*W30mm*T0.45

L8500mm*W30mm*T0.45

Cutting Type:

Automatic+Press Roller+ Dust Clean System

Automatic+Press Roller+ Dust Clean System

Blade Tension System:

Choose Available

Choose Available

Machine N.W:

2000kg

2200kg

Total Motor Power:

9.74kw

11.74kw

Floor Space:

L5800mm*W3700mm*H2400mm

L7800mm*W4500mm*H2400mm
